The F20 is designed to be practical as well as powerful. Integrated front and rear lights, powered by the bike’s main battery, keep you visible during early morning or evening rides. Plus, the aluminium MIK rack can carry up to 25 kg of cargo, making it easy to transport groceries, bags, or whatever else you need.
The Smartmotion F20 is more than just a bike—it’s a solution for everyday travel, with features that make it easy to enjoy every ride. Whether you’re commuting, running errands, or just out exploring, the F20 has everything you need: impressive range, a powerful motor, smooth brakes, and thoughtful details like folding capability and integrated lights.
Get ready to experience a ride that combines comfort, convenience, and performance in one sleek, portable package. The Smartmotion F20 is ready to take you places. Are you ready to take it for a spin?
Specs
| Feature |
Specification |
| BATTERY |
48 volt 20Ah/960Wh |
| FRONT HUB |
Aluminium 36 Hole Nutted |
| FRAME |
Aluminium Hydroformed foldable Frame with Internal Cable routing. Frame Mounted Kickstand, Foldable Pedals |
| SPOKES |
Stainless 13G Front & 12G Rear |
| FORK |
65mm Suspension Fork. 34mm Stanchion with Lock-Out Function |
| RIM |
20x4.0 Double Wall Strong Allow BK |
| HEAD SET |
Sealed Bearing |
| TYRE |
Arisun 20x4.0 Puncture Resistant Fat Tyres |
| HANDLE BAR |
Aluminium |
| DERAILLEUR |
Shimano RD-M310-L- 8 Speed |
| SADDLE |
Velo Comfort Seat |
| MOTOR |
Smartmotion Rear Motor 48 500W 80N.M of High Torque with Cassette Body |
| SEAT POST |
EXA 525 35*350mm Suspension |
| SENSOR |
Cadence Sensor |
| BRAKE |
Tektro E350 Dual Piston Hydraulic Disc BRakes, Cut Off Function with 180mm Rotor |
| DISPLAY |
Centre-mounted C610E LCD Console with 5 Level Pedal Assist |
| CHAINWHEEL |
48T Chainring |
| TOP SPEED |
Capped at 25km/h. (Unrestricted: 40km/h) |
| CHAIN |
8 speed |
| RANGE |
Eco Mode up to 200km |
| CASSETTE |
Shimano 8 Speed 11-34T Wide Range Cassette |
| MAX LOAD |
150kg, Rider weight up to 125kg, cargo limit of 25kg. Bike weighs 36kg |
| RACK |
Aluminium MIK Rack with a Capacity of 25kg |
| LIGHT |
Integrated Front & Rear Light System, Powered from the Main Battery |
| GEARS |
Shimano SL-M3158R 8 Speed |
| CABLES |
Marine-rated Cable Plugs on all Components for simple and quick servicing/replacement |
| CONTROLLER |
48 Volt Sine Wave |
| CHARGER |
48 Volt 3A (54.4 Volt Max Voltage) |
