Tern

Tern HSD P10

Regular price
$6,995.00 AUD
Unit price
per
Tax included

Colour

Blue Green

Pay in 4 interest-free installments of $133.12 with

Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas.

  • What makes it a P10?

    • Bosch Performance Line motor with Bosch Smart System provides up to 75 Nm of torque and increases your pedaling power by up to 340%
    • Detachable and easy-to-understand Intuvia 100 display
    • 1x10-speed Shimano Deore groupset with trigger shifter

    HSD Highlights

    • Control all Smart System functions at your fingertips via the Bosch eBike Flow App: keep your e-bike system up-to-date with over-the-air updates, activate the eBike Lock, customize riding modes, view bike information, connect to dealers, and more!
    • Bosch PowerPack 545 battery provides long range of up to 121 km (76 mi)
    • Cargo and passenger-ready: large rear rack capacity of 80 kg (176 lb) means you can carry one infant to a medium-sized adult passenger, or lots of cargo
    • Fits riders 150 - 195 cm (4’11” - 6’5”) with an easily-adjustable cockpit
    • Tested for safety and reliability: frame and fork are EFBE-tested up to the 180 kg (397 lb) Maximum Gross Vehicle Weight

    Specifications

    Speeds 1 × 10
    Weight 27.6 kg (60.8 lb)
    Gear Inches 30 - 97" (2.36 - 7.72 m)
    Folding Size 165 × 39.5 × 87 cm (65 × 15.6 × 34.3 in)
    Folding Time 5 seconds
    Frame Size One size
    Seatpost to Handlebar 54.5 - 62.5 cm (21.5 - 24.6 in)
    Saddle to Pedal 70 - 102.5 cm (27.6 - 40.4 in)
    Suggested Rider Height 150 - 195 cm (59.1 - 76.8 in)
    Max Gross Vehicle Weight 180 kg (396.8 lb)
    Max Rider Weight 120 kg (264.6 lb)
    Frame
    Frame Tern HSD, 6061-AL, sliding dropouts, EFBE Tri-Test approved 180 kg
    Fork Suntour custom, tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel
    Cockpit
    Handlepost Tern Physis 3D, 12°, 290 mm
    Stem Tern Andros, adjustable
    Headset Tern Flux Pro Taper by FSA, angular contact bearings
    Handlebar Tern Sweep, 6061-AL
    Grips Ergon
    Saddle Tern Upright by Velo
    Seatpost Tern Telescope, 34.9/30.9 mm
    Seatpost Clamp Tern Collar
    Brakes
    Front Brake Tektro hydraulic disc, 180 mm rotor
    Rear Brake Tektro hydraulic disc, 160 mm rotor
    Brake Levers Tektro hydraulic disc
    Wheels
    Front Wheel Tern Atlas H cargo wheel
    Rear Wheel Tern Atlas H cargo wheel
    Front Hub Novatec, thru-axle, sealed bearings
    Rear Hub Novatec, sealed cartridge bearing, disc
    Spokes & Nipples Stainless steel
    Rims Tern Atlas H, 35 mm wide
    Tyres Schwalbe Big Apple, 55-406, Reflex, puncture protection
    Transmission
    Shifter Shimano Deore 1×10-speed trigger
    Rear Derailleur Shimano Deore Shadow+
    Crankset Tern HSD custom
    Cassette Shimano 11-36T, 10-speed
    Bottom Bracket Motor integrated
    Chain KMC eBike 10-speed, EPT coated
    Pedals Urban, non-slip
    E-System
    Motor Bosch Performance, 75 Nm, up to 25 km/h (EU) or 20 mph (US)
    Battery Bosch PowerPack 545 Wh
    Display Bosch Intuvia 100 with LED remote
    Range 51-121 km (32-76 mi)
    Charger 220V/4A (EU) or 100-240V/4A (US)
    Extras
    Bell Pitch Plus, brass
    Chainguard Tern custom full cover
    Kickstand Ursus, rear mount
    Lights Front: Tern Valo Direct (190 lm) / Rear: Herrmans H-Trace
    Rack Atlas H rack, 80 kg capacity
    Frame Lock ABUS, keyed-alike with battery
